If you rely on a well for your garden, lawn, or home water supply, choosing the right shallow well jet pump is one of the most important decisions you'll make. The wrong pump means poor water pressure, wasted energy, or a pump that burns out within months. This guide covers everything you need to know.
What Is a Shallow Well Jet Pump?
A shallow well jet pump draws water from a well or underground water source up to 25 feet deep. It uses a jet ejector to create suction, pulling water up and pressurizing it for use in your home, garden, or irrigation system. Unlike submersible pumps, jet pumps are installed above ground — making them easy to access for maintenance.
Shallow Well Jet Pump vs. Deep Well Pump: What's the Difference?
- Shallow well jet pump — for wells up to 25 ft deep; installed above ground; simpler and more affordable
- Deep well pump — for wells 25–400 ft deep; submersible design; higher cost
If your well is 25 feet or less, a shallow well jet pump is the right choice.
Step 1: Measure Your Well Depth
Before buying, confirm your well depth. Shallow well jet pumps are rated for wells up to 25 feet. If your water source is deeper, you'll need a deep well or submersible pump instead.
Step 2: Calculate Your Flow Rate Needs
Flow rate is measured in GPH (gallons per hour) or GPM (gallons per minute). Here's a quick reference:
- Garden irrigation (small yard) — 500–800 GPH is sufficient
- Garden irrigation (large yard or farm) — 1,000–1,500 GPH recommended
- Household water supply — 1,200–1,700 GPH for a typical family home
Step 3: Choose the Right Horsepower
- 1 HP — ideal for small gardens and light irrigation; up to ~865 GPH
- 1.5 HP — best for medium gardens and household use; up to ~1,340 GPH
- 1.6 HP — for large gardens, farms, or high-demand applications; up to ~1,700 GPH
Step 4: Check the Pressure Rating
Pump pressure is measured in PSI. For most home and garden applications, a pump with 40–60 PSI output is ideal. Higher PSI means stronger water pressure at the tap or sprinkler head.
Some pumps come with a built-in pressure tank, which maintains consistent water pressure and reduces pump cycling — extending the pump's lifespan significantly.
Step 5: Consider the Build Material
For longevity, look for pumps with stainless steel impellers and pump bodies. Stainless steel resists corrosion from minerals and sediment in well water, while thermoplastic housings are lighter but less durable over time.
Our Shallow Well Jet Pump Recommendations
Browse our full range of garden well pumps — all featuring stainless steel construction and reliable performance for home and garden use.
- FOTING 1 HP Shallow Well Jet Pump (865 GPH) — best for small gardens and light irrigation
- FOTING 1.5 HP Shallow Well Jet Pump (1,340 GPH) — ideal for medium gardens and household water supply
- FOTING 1.6 HP Shallow Well Jet Pump (1,600 GPH) — for large gardens and high-demand use
- FOTING 1.5 HP Shallow Well Pump with Pressure Tank (164 FT) — best for consistent household water pressure
- FOTING 1.6 HP Shallow Well Pump with Pressure Tank (180 FT) — maximum flow with built-in pressure regulation
Installation Tips
- Install the pump as close to the water source as possible to minimize suction lift
- Use a foot valve at the bottom of the suction pipe to maintain prime
- Prime the pump before first use by filling the pump body with water
- Install a pressure switch and pressure gauge for automatic on/off operation
- Protect the pump from freezing temperatures — install indoors or in an insulated pump house
Maintenance Tips
- Check and clean the inlet strainer every 3 months
- Inspect the pressure tank bladder annually
- Lubricate the motor bearings if the pump runs loudly
- Winterize by draining all water from the pump if temperatures drop below freezing
Final Thoughts
The right shallow well jet pump delivers reliable water pressure for your garden, lawn, or home — season after season. Match the horsepower and flow rate to your actual needs, choose stainless steel for durability, and consider a pressure tank model for the most consistent performance.
Need help choosing? Contact our team — we're happy to recommend the right pump for your setup.
